Composite Body DOT Air Brake Push In Fitting Bulkhead Union, 1/4″ OD Tube, 9/16″ UNF Thread

$7.00

Composite Body DOT Air Brake Fitting
1/4″ Outside Diameter Tube
9/16″ UNF Thread
-40°F to +140°F Operating Range
SAE and DOT Compliant
Operates up to 145 PSI in Air Brake Systems

Factory Direct Item

This product ships direct from our manufacturer. Lead times may vary. Please contact customer service for availablitiy.

SKU: TF-BU-2556-CDOT Category: Air Brake Fittings

Description
Additional information

The Composite Body DOT Air Brake Fitting is built for high performance in tough conditions. This bulkhead union push in fitting connects two 1/4″ air brake tubes together. This fitting fits 9/16″ UNF threads. It meets FMVSS (DOT) and SAE standards, handling up to 145 psi, ideal for various vehicle air brake systems. Its rugged polybutylene terephthalate and brass body resists UV rays and vibration, ensuring durability.

This fitting withstands gasoline, diesel fuel, and common road and cleaning chemicals, enhancing longevity. Featuring a one-touch connection, this fitting reduces installation time and cost, offering dependable performance and safety for industrial and automotive air brake systems.

This fitting is available in multiple shapes and configurations, allowing for diverse vehicle needs and simplified installation.

This fitting has a 7 Ncm^3/min or less leak rate at -40 °F.
Additionally, this fitting has a proof pressure of 1200 psi at 75 °F and a proof pressure of 450 psi at 200 °F.

Weight	0.07 lbs
Dimensions	2 × 2 × 1 in
Hose Type	Nylon Air Brake Tube
Hose Fittings	Air Brake Tubing
Hose OD	0.156"
Working Pressure	145 PSI
Working Temperature	-40° F to +140° F
Product Type	DOT Air Brake Fitting
Cross Reference	820400C
Hose Fitting Type	Bulkhead Union
